27
Group 13
ANALOGUE INPUTS
1301 MINIMUM AI1
Minimum value of AI1 in per cent. Defines relative analogue input
value where frequency reference reaches minimum value.
Range: 0 - 100 %
Default value: 0 %
Group 15
ANALOGUE OUTPUT
1503 AO CONTENT MAX
Defines output frequency where analogue output reaches 20 mA.
Range: 0 -300 Hz.
Default value: 50 Hz
Note! Analogue output content is programmable. Values given here
are valid only if other analogue output configuration parameters have
not been modified. Description of all parameters is given in “ACS140
Complete Parameter List” starting on page 39.
Group 20
LIMITS
2003 MAX CURRENT
Maximum output current.
Range: 0.5* I
N
- 1.5* I
N
, where I
N
is nominal current of the ACS140.
Default value: 1.5 * I
N
2008 MAXIMUM FREQ
Maximum output frequency.
Range: 0 - 300 Hz
Default value: 50 Hz
!
The table continues on the next page.
Code Name User S
