40
Group 10
COMMAND INPUTS
1001
EXT1 COMMANDS 0-10 1 2/4 !!
1002
EXT2 COMMANDS 0-10 1 0 (NOT SEL) !!
1003
DIRECTION 1-3 1 3 (REQUEST) !!
Group 11
REFERENCE SELECT
1101
KEYPAD REF SEL 1-2 1 1 (REF1(HZ))
1102
EXT1/EXT2 SEL 1-8 1 6 (EXT1) !!
1103
EXT REF1 SELECT 0-11 1 1 (AI1) !!
1104
EXT REF1 MIN 0-300 Hz 1 Hz 0 Hz
1105
EXT REF1 MAX 0-300 Hz 1 Hz 50 Hz
1106
EXT REF2 SELECT 0-11 1 0 (KEYPAD) !!
1107
EXT REF2 MIN 0-100 % 1 % 0 %
1108
EXT REF2 MAX 0-500 % 1 % 100 %
1109
CONST EXT REF1 0-300 Hz 0.1 Hz 50 Hz or
60 Hz
1110
CONST EXT REF2 0-100 % 0.1 % 40 %
Group 12
CONSTANT SPEEDS
1201
CONST SPEED SEL 0-10 1 3/0 !!
1202
CONST SPEED 1 0-300 Hz 0.1 Hz 5 Hz
1203
CONST SPEED 2 0-300 Hz 0.1 Hz 10 Hz
1204
CONST SPEED 3 0-300 Hz 0.1 Hz 15 Hz
1205
CONST SPEED 4 0-300 Hz 0.1 Hz 20 Hz
1206
CONST SPEED 5 0-300 Hz 0.1 Hz 25 Hz
1207
CONST SPEED 6 0-300 Hz 0.1 Hz 40 Hz
1208
CONST SPEED 7 0-300 Hz 0.1 Hz 50 Hz
Group 13
ANALOGUE INPUTS
1301
MINIMUM AI1 0-100 % 1 % 0 %
1302
MAXIMUM AI1 0-100 % 1 % 100 %
1303
FILTER AI1 0-10 s 0.1 s 0.1 s
1304
MINIMUM AI2 0-100 % 1 % 0 %
1305
MAXIMUM AI2 0-100 % 1 % 100 %
1306
FILTER AI2 0-10 s 0.1 s 0.1 s
Group 14
RELAY OUTPUTS
1401
RELAY OUTPUT 10-11 1 3
(
FAULT (-1))
1402
RELAY OUTPUT 20-11 1 2 (RUN)
Group 15
ANALOGUE OUTPUT
1501
AO CONTENT 102-130 1 103
1502
AO CONTENT MIN * * 0.0 Hz
1503
AO CONTENT MAX * * 50 Hz
1504
MINIMUM AO 0.0-20.0 mA 0.1 mA 0 mA
1505
MAXIMUM AO 0.0-20.0 mA 0.1 mA 20 mA
Code Name Range Resolution Default User S M
