ABB ACS140 - Page 50

41
1506 FILTER AO 0-10 s 0.1 s 0.1 s
Group 16
SYSTEM CONTROLS
1601
RUN ENABLE 0-6 1 0 (NOT SEL) !!
1602
PARAMETER LOCK 0-2 1 1 (OPEN)
1604
FAULT RESET SEL 0-7 1 6 (START/
STOP)
!
1608
DISPLAY ALARMS 0-1 1 0 (NO)
Group 20
LIMITS
2003
MAX CURRENT 0.5*I
N
- 1.5*I
N
0.1 A 1.5*I
N
2005 OVERVOLT CTRL 0-1 1 1 (ENABLE)
2006
UNDERVOLT CTRL 0-2 1 1 (ENABLE
TIME)
2007
MINIMUM FREQ 0-300 Hz 1 Hz 0 Hz
2008
MAXIMUM FREQ 0-300 Hz 1 Hz 50 Hz !
Group 21
START/STOP
2101
START FUNCTION 1-4 1 1 (RAMP) !
2102
STOP FUNCTION 1-2 1 1 (COAST)
2103
TORQ BOOST CURR 0.5*I
N
- 2.0*I
N
0.1 A 1.2*I
N
!
2104
STOP DC INJ TIME 0-250 s 0.1 s 0 s
2105
PREMAGN SEL 0-6 1 0 (NOT SEL) !!
2106
PREMAGN MAX TIME 0-25.0 s 0.1 s 2.0 s
2107
START INHIBIT 0-1 1 1 (ON)
Group 22
ACCEL/DECEL
2201
ACC/DEC 1/2 SEL 0-5 1 5 (DI5) !!
2202
ACCELER TIME 1 0.1-1800 s 0.1; 1 s 5 s !
2203
DECELER TIME 1 0.1-1800 s 0.1; 1 s 5 s !
2204
ACCELER TIME 2 0.1-1800 s 0.1; 1 s 60 s
2205
DECELER TIME 2 0.1-1800 s 0.1; 1 s 60 s
2206
RAMP SHAPE 0-3 1 0 (LINEAR)
Group 25
CRITICAL FREQ
2501
CRIT FREQ SEL 0-1 1 0 (OFF)
2502
CRIT FREQ 1 LO 0-300 Hz 1 Hz 0 Hz
2503
CRIT FREQ 1 HI 0-300 Hz 1 Hz 0 Hz
2504
CRIT FREQ 2 LO 0-300 Hz 1 Hz 0 Hz
2505
CRIT FREQ 2 HI 0-300 Hz 1 Hz 0 Hz
Group 26
MOTOR CONTROL
2603
IR COMPENSATION 0-30 V FOR
200 V
UNITS;
0-60 V
FOR
400 V
UNITs
1 10 V
2604
IR COMP RANGE 0-300 Hz 1 Hz 50 Hz
2605
LOW NOISE 0-2 1 0
(
STANDARD)
!
2606
U/f RATIO 1-2 1 1 (LINEAR) !!
Code Name Range Resolution Default User S M
