42
2607 SLIP COMP RATIO 0-250 % 1 % 0 %
Group 30
FAULT FUNCTIONS
3001
AI<MIN FUNCTION 0-3 1 1 (FAULT)
3002
PANEL LOSS 1-3 1 1 (FAULT)
3003
EXTERNAL FAULT 0-5 1 0 (NOT SEL)
3004
MOT THERM PROT 0-2 1 1 (FAULT)
3005
MOT THERM TIME 256-9999 s 1 s 500 s
3006
MOT LOAD CURVE 50-150 % 1 % 100 %
3007
ZERO SPEED LOAD 25-150 % 1 % 70 %
3008
BREAK POINT 1-300 Hz 1 Hz 35 Hz
3009
STALL FUNCTION 0-2 1 0 (NOT SEL)
3010
STALL CURRENT 0.5*I
N
- 1.5*I
N
0.1 A 1.2* I
N
3011 STALL FREQ HI 0.5-50 Hz 0.1 Hz 20 Hz
3012
STALL TIME 10-400 s 1 s 20 s
3013
AI1 FAULT LIMIT 0-100 % 1 % 0 %
3014
AI2 FAULT LIMIT 0-100 % 1 % 0 %
Group 31
AUTOMATIC RESET
3101
NR OF TRIALS 0-5 1 0 !
3102
TRIAL TIME 1.0-180.0 s 0.1 s 30 s
3103
DELAY TIME 0.0-3.0 s 0.1 s 0 s !
3104
AR OVERCURRENT 0-1 1 0 (DISABLE)
3105
AR OVERVOLTAGE 0-1 1 0 (DISABLE)
3106
AR UNDERVOLTAGE 0-1 1 0 (DISABLE) !
3107
AR AI<MIN 0-1 1 0 (DISABLE)
Group 32
SUPERVISION
3201
SUPERV 1 PARAM 102 -130 1 103
3202
SUPERV 1 LIM LO **0
3203
SUPERV 1 LIM HI **0
3204
SUPERV 2 PARAM 102 - 130 1 103
3205
SUPERV 2 LIM LO **0
3206
SUPERV 2 LIM HI **0
Group 33
INFORMATION
3301
SW VERSION 0.0.0.0-f.f.f.f - -
3302
TEST DATE yy.ww - -
Group 40
PID-CONTROL
4001
PID GAIN 0.1-100 0.1 1.0 !
4002
PID INTEG TIME 0.1-320 s 0.1 s 60 s !
4003
PID DERIV TIME 0-10 s 0.1 s 0 s
4004
PID DERIV FILTER 0-10 s 0.1 s 1 s
4005
ERROR VALUE INV 0-1 1 0 (NO)
4006
ACTUAL VAL SEL 1-9 1 1 (ACT1) !
4007
ACT1 INPUT SEL 1-2 1 2 (AI2) !
Code Name Range Resolution Default User S M
