Actual signals and parameters 19
NOT SEL User parameter set change is not possible through a digital
input. Parameter sets can be changed only from the control
panel.
0
DI1 User parameter set control through digital input DI1. Falling
edge of digital input DI1: User parameter set 1 is loaded into
use. Rising edge of digital input DI1: User parameter set 2 is
loaded into use.
1
DI2 See selection DI1.2
DI3 See selection DI1.3
DI4 See selection DI1.4
DI5 See selection DI1.5
DI1,2 User parameter set selection through digital inputs DI1 and
DI2. 1 = DI active, 0 = DI inactive.
7
DI2,3 See selection DI1,2.8
DI3,4 See selection DI1,2.9
DI4,5 See selection DI1,2.10
DI1,2,3 User parameter set selection through digital inputs DI1, DI2
and DI3. 1 = DI active, 0 = DI inactive.
12
DI2,3,4 See selection DI1,2,3. 13
DI3,4,5 See selection DI1,2,3. 14
DI1(INV) User parameter set control through inverted digital input
DI1. Falling edge of inverted digital input DI1: User
parameter set 2 is loaded into use. Rising edge of inverted
digital input DI1: User parameter set 1 is loaded into use.
-1
DI2(INV) See selection DI1(INV).-2
DI3(INV) See selection DI1(INV).-3
DI4(INV) See selection DI1(INV).-4
All parameters
No. Name/Value Description Def/FbEq
DI1 DI2 User parameter set
0 0 User parameter set 1
1 0 User parameter set 2
0 1 User parameter set 3
1 1 User parameter set 4
DI1 DI2 DI3 User parameter set
0 0 0 User parameter set 1
1 0 0 User parameter set 2
0 1 0 User parameter set 3
1 1 0 User parameter set 4
0 0 1 User parameter set 5
1 0 1 User parameter set 6
x 1 1 No reaction
