20 Actual signals and parameters
DI1,2(INV) User parameter set selection through inverted digital inputs
DI1 and DI2. 1 = DI inactive, 0 =DI active.
-7
DI2,3(INV) See selection DI1,2(INV). -8
DI3,4(INV) See selection DI1,2(INV). -9
DI4,5(INV) See selection DI1,2(INV). -10
DI1,2,3(INV) User parameter set selection through inverted digital inputs
DI1, DI2 and DI3. 1 = DI inactive, 0 =DI active.
-12
DI2,3,4(INV) See selection DI1,2,3(INV). -13
DI3,4,5(INV) See selection DI1,2,3(INV). -14
1614 LOAD USER
SET
Selects which user set will be loaded NOT SEL
Done No user set will be loaded. 0
USER S1
LOAD
User set1 will be loaded. 1
USER S2
LOAD
User set2 will be loaded. 2
USER S3
LOAD
User set3 will be loaded. 3
USER S4
LOAD
User set4 will be loaded. 4
USER S5
LOAD
User set5 will be loaded. 5
USER S6
LOAD
User set6 will be loaded. 6
1615 SAVE USER
SET
Selects which user set will be saved NOT SEL
Done No user set will be saved. 0
USER S1
SAVE
User set1 will be saved. 1
All parameters
No. Name/Value Description Def/FbEq
DI1 DI2 User parameter set
1 1 User parameter set 1
0 1 User parameter set 2
1 0 User parameter set 3
0 0 User parameter set 4
DI1 DI2 DI3 User parameter set
1 1 1 User parameter set 1
0 1 1 User parameter set 2
1 0 1 User parameter set 3
0 0 1 User parameter set 4
1 1 0 User parameter set 5
0 1 0 User parameter set 6
x 0 0 No reaction
