Actual signals and parameters 23
SMOOTH
START
Smooth start ramp time will be effect in ramp time according
to settings of parameter 2621...2624.
11
DI1(INV) Inverted digital input DI1. 0 = ramp pair 2, 1 = ramp pair 1. -1
DI2(INV) See selection DI1(INV).-2
DI3(INV) See selection DI1(INV).-3
DI4(INV) See selection DI1(INV).-4
DI5(INV) See selection DI1(INV).-5
25 CRITICAL
SPEEDS
Speed bands within which the drive is not allowed to
operate.
2502 CRIT SPEED 1
LO
Defines the minimum limit for critical speed/frequency range
1.
0.0 Hz /
1rpm
0.0…1400.0 Hz
/ 0…32000 rpm
Limit in rpm. Limit in Hz if parameter 9904 MOTOR CTRL
MODE setting is SCALAR: FREQ. The value cannot be
above the maximum (parameter 2503 CRIT SPEED 1 HI).
1 = 0.1 Hz
/ 1 rpm
2503 CRIT SPEED 1
HI
Defines the maximum limit for critical speed/frequency
range 1.
0.0 Hz /
1rpm
0.0…1400.0 Hz
/ 0…32000 rpm
Limit in rpm. Limit in Hz if parameter 9904 MOTOR CTRL
MODE setting is SCALAR: FREQ. The value cannot be
below the minimum (parameter 2502 CRIT SPEED 1 LO).
1 = 0.1 Hz
/ 1 rpm
2504 CRIT SPEED 2
LO
See parameter 2502 CRIT SPEED 1 LO. 0.0 Hz /
1rpm
0.0…1400.0 Hz
/ 0…32000 rpm
See parameter 2502.1 = 0.1Hz
/ 1 rpm
2505 CRIT SPEED 2
HI
See parameter 2503 CRIT SPEED 1 HI. 0.0 Hz /
1rpm
0.0…1400.0 Hz
/ 0…32000 rpm
See parameter 2503.1 = 0.1Hz
/ 1 rpm
2506 CRIT SPEED 3
LO
See parameter 2502 CRIT SPEED 1 LO. 0.0 Hz /
1rpm
0.0…1400.0 Hz
/ 0…32000 rpm
See parameter 2502.1 = 0.1Hz
/ 1 rpm
2507 CRIT SPEED 3
HI
See parameter 2503 CRIT SPEED 1 HI. 0.0 Hz /
1rpm
0.0…1400.0 Hz
/ 0…32000 rpm
See parameter 2503.1 = 0.1Hz
/ 1 rpm
26 MOTOR
CONTROL
Motor control variables
2611 USER
DEFINED F1
Defines the first frequency point of the custom U/f curve. 10.0 Hz
0.0…1400.0 Hz Frequency 1 = 0.1 Hz
2613 USER
DEFINED F2
Defines the second frequency point of the custom U/f curve. 20.0 Hz
All parameters
No. Name/Value Description Def/FbEq
