Operation
18
Initially, the panel is in the Output mode, where you can
start, stop, change the direction, switch between local and
remote control, modify the reference value and monitor up
to three actual values. To do other tasks, go first to the
Main menu and select the appropriate option on the
menu. The status line (see section Status line on page 11)
shows the name of the current menu, mode, item or state.
List of tasks
The table below lists common tasks, the mode in which you can perform them,
abbreviations of the options in the Main menu and the page number where the steps
to do the task are described in detail.
Task Mode / Main menu
option
Abbreviations of the
Main menu options *
Page
How to get help Any - 19
How to find out the panel version Any - 19
How to start and stop the drive Output - 20
How to switch between local and remote control Any - 20
How to change the direction of the motor rotation Any - 21
How to select the monitored signals Parameters PARAMETERS 22
How to set the speed, frequency, torque or position
reference in the Output mode
Output - 23
How to adjust the display contrast Output - 23
How to change the value of a parameter Parameters PARAMETERS 24
How to change the value of value pointer parameters Parameters PARAMETERS 25
How to change the value of bit pointer parameter to point to
the value of a bit in another signal
Parameters PARAMETERS 27
How to change the value of bit pointer parameter to fixed
0(FALSE) or 1(TRUE)
Parameters PARAMETERS 29
How to view faults Fault Logger FAULT LOGGER 31
How to reset faults and alarms Fault Logger FAULT LOGGER 31
How to show/hide the clock, change date and time formats,
set the clock and enable/disable automatic clock transitions
according to the daylight saving changes
Time & Date TIME & DATE 32
How to copy parameters from the drive to the control panel Parameter Backup PAR BACKUP 35
How to restore parameters from the control panel to the
drive
Parameter Backup PAR BACKUP 35
How to view backup information Parameter Backup PAR BACKUP 41
How to edit reference value Reference Edit REF EDIT 42
How to view drive info Drive Info DRIVE INFO 43
* Main menu options actually shown in the control panel.
PARAMETERS
FAULT LOGGER
TIME & DATE
EXIT ENTER
00:00
MAIN MENU 1
LOC
50 A
10 Hz
7 %10.
0.
49.
LOC
DIR
MENU
00:00
30.00rpm
