Operation

How to select the monitored signals

Step Action Display

1. You can select which signals are monitored in the Output mode and how they

are displayed with group 17 PANEL DISPLAY parameters. See page 24 for

detailed instructions on changing parameter values.

1701 SIGNAL1 PARAM

PAR EDIT

01.03

CANCEL NEXT

00:00

LOC

1702 SIGNAL2 PARAM

PAR EDIT

01.04

CANCEL NEXT

00:00

LOC

1703 SIGNAL3 PARAM

PAR EDIT

01.06

CANCEL NEXT

00:00

LOC

Table of Contents5
About the Manual7
What this Chapter Contains7
Compatibility7
Safety7
Intended Audience7
Product and Service Inquiries7
Product Training7
Providing Feedback on ABB Drives Manuals7
Hardware Description9
What this Chapter Contains9
About Control Panels9
Compatibility9
ACSM1 Control Panel10
Features10
Overview10
Maintenance10
Status Line11
Installation13
What this Chapter Contains13
Connecting the Panel to the Drive13
The Cable13
Mounting the Control Panel14
Mounting Template15
Gasket16
Operation17
What this Chapter Contains17
Basics of Operation17
List of Tasks18
Help and Panel Version - any Mode19
How to Get Help19
How to Find out the Panel Version19
Basic Operations - any Mode20
How to Start, Stop and Switch between Local and Remote Control20
Output Mode21
How to Change the Direction of the Motor Rotation21
How to Select the Monitored Signals22
How to Set the Speed, Frequency, Torque or Position Reference in the Output Mode23
How to Adjust the Display Contrast23
Parameters24
How to Select a Parameter and Change Its Value24
How to Change the Value of Value Pointer Parameters25
How to Change the Value of Bit Pointer Parameter to Point to the Value of a Bit in Another Signal27
How to Change the Value of Bit Pointer Parameter to Fixed 0 (FALSE) or 1 (TRUE)29
Fault Logger31
How to View Faults31
How to Reset Faults31
Time & Date32
How to Show or Hide the Clock, Change Display Formats, Set the Date and Time and Enable or Disable Clock Transitions According to the Daylight Saving Changes32
Parameter Backup34
How to Backup and Restore Parameters35
How to View Information about the Backup41
Reference Edit42
How to Edit Reference Value42
Drive Info43
How to View Drive Info43
