ABB ACSM1 Control Panel User Manual

Operation
40
Trying to load a user set between different firmware versions
If you try load a user set between different firmware versions, the panel shows you
the following fault information:
Step Action Display
1. Go to the Parameters option by selecting PARAMETERS on the main menu as
shown in section Parameters on page 24.
A user set is loaded through parameter 16.09 USER SET SEL. Select
parameter group 16 SYSTEM with keys and .
2. Press to select the parameter group 16. Select parameter 16.09 USER
SET SEL with keys and . Current value of each parameter is
shown below its name.
3. Press .
Select the user set you want to load with keys and .
Press .
4. Panel shows a text identifying the fault.
EXIT SEL
00:00
11 START/STOP MODE
12 DIGITAL IO
13 ANALOGUE INPUTS
15 ANALOGUE OUTPUTS
16 SYSTEM
PAR GROUPS 16
LOC
SEL
1603 PASS CODE9901
1604 PARAM RESTORE
1607 PARAM SAVE
1609 USER SET SEL
No request
PARAMETERS
EXIT
EDIT00:00
LOC
EDIT
1609 USER SET SEL
PAR EDIT
No request
CANCEL SAVE
00:00
[1]
LOC
SAVE
1609 USER SET SEL
PAR EDIT
Load set 1
CANCEL SAVE00:00
[2]
LOC
FAULT 310
USERSET LOAD
FAULT
RESET
EXIT
LOC
