ABB aquamaster - Transmitter and GSM Antenna Installation

Electronic Commercial Water Meter
AquaMaster™ 2 Mechanical Installation
IM/AM Issue 13 9
2.3 Transmitter Dimensions
Fig. 2.18 Transmitter Dimensions
Fig. 2.19 GSM Antenna Installation
Transmitter Mounting Plate
176 (7)
140
(5.5)
Installation and wiring acces
s
300 (11.8) minimum 450 (17.7)
preferred
Allowance for cable bend - each side
130 (5.1)  standard)
230 (9)  armored)
155mm
(6.1)
146 (5.75)
125 (4.9)
170
(6.7)
ø6.5 (
1
/4)
ø13 (
1
/2)
ø6.5 (
1
/4)
150
(5.9)
AquaMaster
Dimensions in mm (in.)
50mm50mm
Remote
Antenna
Integral
Antenna
