ControlMaster CM10, CM15, CM30 and CM50
Universal process controllers and indicators,
1
/8,
1
/4 and
1
/2 DIN 3 Communication Overview
IM/CM/C–EN 7
3.2 PC Configuration
In addition to configuration via the front panel, the ControlMaster can be configured from a PC via the infrared port (configuration
files can be stored locally on a PC and transferred to the controller via the infrared port).
For further information contact your sales representative.
Fig. 3.3 PC Configuration Software
Fig. 3.4 Transferring a Configuration File via the Infrared Port
