ControlMaster CM15
Universal process indicator,
1
/
8
DIN
14 DS/CM15–EN Rev. J | ControlMaster CM15 | Universal process indicator,
1
/
8
DIN
Display range
–9999 to 99999
Update rate
125 ms
Common mode noise rejection
> 120 dB at 50 / 60 Hz with 300 imbalance resistance
Normal (series) mode noise rejection
> 60 dB at 50 / 60 Hz
CJC rejection ratio
0.05 °C/°C change in ambient temperature
Temperature stability
0.02 %/°C or 2 µV/°C (1 µV/°F)
Long term (input) drift
< 0.1 % of reading or 10 µV annually
Input impedance
> 10 M (mV input)
10 (mA input)
Inputs
Thermocouple Maximum range °C (°F) Accuracy (% of reading)
B –18 to 1800
(0 to 3270)
0.1 % or ±2 °C (3.6 °F)
(above 200 °C [392 °F]) *
E –100 to 900
(–140 to 1650)
0.1 % or ±0.5 °C (0.9 °F)
J –100 to 900
(–140 to 1650)
0.1 % or ±0.5 °C (0.9 °F)
K –100 to 1300
(–140 to 2350)
0.1 % or ±0.5 °C (0.9 °F)
L –100 to 900
(–140 to 1650)
0.1 % or ±1.5 °C (2.7 °F)
N –200 to 1300
(–325 to 2350)
0.1 % or ±0.5 °C (0.9 °F)
R –18 to 1700
(0 to 3000)
0.1 % or ±1 °C (1.8 °F)
(above 300 °C [540 °F]) *
S –18 to 1700
(0 to 3000)
0.1 % or ±1 °C (1.8 °F)
(above 200 °C [392 °F]) *
T –250 to 300
(–400 to 550)
0.1 % or ±0.5 °C (0.9 °F)
(above –150 °C [–238 °F]) *
* Accuracy is not guaranteed at temperatures below this value
RTD Maximum range °C (°F) Accuracy (% of reading)
Pt100 –200 to 600
(–325 to 1100)
0.1 % or ±0.5 °C (0.9 °F)
Linear inputs Standard analog input Accuracy (% of reading)
Millivolts
Milliamps
Volts
Resistance (low)
Resistance (high)
0 to 150 mV
0 to 50 mA
0 to 25 V
0 to 550
0 to 10 k
0.1 % or ±20 µV
0.2 % or ±4 µA
0.2 % or ±20 mV
0.2 % or ±0.1
0.5 % or ±10
Sample Interval 125 ms per sample
Digital inputs
Type Volt-free or 24 V
Minimum pulse
duration
Single input configured – 250 ms
Both inputs configured as analog or digital – 500 ms
Frequency input*
Frequency range
1-signal
0-signal
0 to 6000 Hz
15 to 30 V
–3 to 5 V
*For use with devices with open collector outputs
