ControlMaster CMF160 | Universal process indicator, fieldmount | DS/CMF160–EN Rev. B 3
Highly scalable
The CMF160 is highly scalable in terms of both hardware and software, enabling it to meet the demands of simple indication
duties through to more complex applications. The base CMF160 provides basic indication, totalization and level functionality.
Templates and functionality can be increased by adding function keys to the basic model as shown in Fig. 1, while retaining
previous templates and functionality.
Level Function keys Template Functionality
Base 0 Single PV indication
Single PV with totalizer
Single totalizer
Single level with volume
Process alarms
Totalization
Volume computation
Specific gravity compensation
Minimum, maximum and average calculation
Standard 1 Logic
Math
Custom linearizers
Delay timers
Real time alarms
Bank Control
Template customization
Dual 2 Dual PV indication
Dual PV with totalizer
Dual totalizer
Dual level with volume
Display customization
Fig. 1: Overview of template options
