10 CoriolisMaster FCB400, FCH400 CORIOLIS MASS FLOWMETER | CI/FCB400/FCH400-EN REV. H
… 2 Use in potentially explosive atmospheres
… Ex marking
Additional ordering information FCa4cdefghijklm XXX XXX XX
Option card 1
2 port Ethernet (various protocols) DR6*
1 × active digital output DRH
Option card 2
Power over Ethernet module / Modbus DS8*
1 × active digital output DSH
Connection type
Without U0
1 × M 12 plug connector for Ethernet 1 Port (4 signal lines) UE*
2 × M 12 plug connector for Ethernet 2 Port (4 signal lines) UF*
1 × M 12 plug connector for Ethernet 1 Port (8 signal lines) UG*
1 × RJ45 connector with 5 m cable length attached (4 signal lines) U5*
2 × RJ45 connector with 5 m cable length attached (4 signal lines) UB*
1 × RJ45 connector with 5 m cable length attached (8 signal lines) UC*
1 × RJ45 connector with 10 m cable length attached (4 signal lines) U6*
2 × RJ45 connector with 10 m cable length attached (4 signal lines) DU*
1 × RJ45 connector with 10 m cable length attached (8 signal lines) UH*
1 × RJ45 connector with 15 m cable length attached (4 signal lines) U7*
2 × RJ45 connector with 15 m cable length attached (4 signal lines) UJ*
1 × RJ45 connector with 15 m cable length attached (8 signal lines) UK*
1 × RJ45 connector with 20 m cable length attached (4 signal lines) U8*
2 × RJ45 connector with 20 m cable length attached (4 signal lines) UN*
1 × RJ45 connector with 20 m cable length attached (8 signal lines) UP*
* Only available with single-compartment housing and Ethernet
DANGER
Risk of injury caused by live parts!
When using the outputs of the M6 option digital output or the DRH/DSH option active digital output option cards, all the option
cards used and all pre-installed output circuits must use the ‘Increased safety’ (Ex-e) IP rating.
The ‘Intrinsic safety’ (Ex i) IP rating is not permitted.
