Maximum pilotable power
3000W 3000W 1100W
900W
(125 µF)
7W - 23W (max.
23 lamps)
1-3 Display (Fig. 1)
Channel 1/Channel 2 OFF/ Channel deactivated
Manual forcing of channel ON / Channel active
Random programs Cyclic programs
Holidays icon Keyboard lock
GPS or DCF77 signal
reception indication
Scroll up
Program no. selected
P01-P64
Scroll down
The striped bar on the display also shows:
Progress, ref. Fig.2 (e.g. deletion ref. subsection 3-6).•
Display hours, ref. Fig.3.•
The display shows alternately (for a few seconds) the date and the time and
the programs or forcings set.
i
i
