DCS800 family
▅ Compact
▅ Highest power ability
▅ Simple operation
▅ Comfortable assistants, e.g. for commissioning or
fault tracing
▅ Scalable to all applications
▅ Free programmable by means of integrated
IEC61131-PLC
▅ Individually adaptable to customer requirements
▅ User-defined accessories like external PLC or auto-
mation systems can be included
▅ High power solutions in 6- and 12-pulse up to 20,000
A, 1,500 V
▅ In accordance to usual standards
▅ Individually factory load tested
▅ Detailed documentation
▅ DCS800 module with all necessary accessories
mounted and fully cabled on a panel
▅ Very fast installation and commissioning
▅ Squeezes shut-down-times in revamp projects to a
minimum
▅ Fits into Rittal cabinets
▅ Compact version up to 450 A and Vario version up
to 2,000 A
▅ Proven long life components are re-used, such
as power stacks, (main) contactors, cabinets and
cabling / busbars, cooling systems
▅ Use of up-to-date communication facilities
▅ Increase of production and quality
▅ Very cost-effective solution
▅ Open Rebuild Kits for nearly all existing DC drives
▅ tailor-made solutions for…
▅ BBC PxD ▅ BBC SZxD
▅ ASEA TYRAK ▅ other manufacturers
DCS800-S modules
The versatile drive for any
application
20 … 5,200 A
DC
0 … 1,160 V
DC
230 … 1,000 V
AC
IP00
DCS800-A enclosed
converters
Complete drive solutions
20 … 20,000 A
DC
0 … 1,500 V
DC
230 … 1,200 V
AC
IP21 – IP54
DCS800-E series
Pre-assembled drive-kits
20 … 2,000 A
DC
0 … 700 V
DC
230 … 600 V
AC
IP00
DCS800-R Rebuild Kit
Digital control-kit for existing
powerstacks
20 … 20,000 A
DC
0 … 1,160 V
DC
230 … 1,200 V
AC
IP00
