3ADW000191R0500 DCS800 Quick guide edisf e
DCS800 DC Drives
Technical data
Mains supply volt. 230...1,200 V,
+/–10 %, 3~
Frequency 50...60 Hz, +/–5
Hz
Electronics supply 115...230 V,
–15 % / +10 %, 1~
DC Output current 20...5,200 A
Overload capability 200 %
Ambient conditions
Ambient temperat. 0° ... +40° C
40° ... 55°C with
reduction
Storage temperat. –40° ... +55° C
Transport temper. –40° ... +70° C
Relative humidity 5 ... 95 %, not
condensing
(max. 50 % betw.
0°...5° C)
Pollution degree Class 2
Protection class IP 00
Altitude < 1,000 m height
above sea level:
nominal Current
> 1,000 m height
above sea level:
with reduction
I/O
Digital inputs: 8 standard, up to
14 optional
Digital outputs: 8 standard, up
to 12 optional
Analog inputs: 4 standard +/–
10 V; 0/2…10 V, up to 8 optional
+/ 20 mA; 0/4…20 mA
Analog outputs: 3 standard (1x
I
act
) +/-10 V; 0/2…10 V, up to 7
optional –20 mA; 0/4…20 mA
PC-Tools
DriveWindow Light: free of
charge with every converter,
Standard RS232 PC-connection
DriveWindow: Real-time optical
connection
ControlBuilder DCS800:
IEC61131 programming tool
DriveSize: Converter- and motor
dimensioning
Maintenance / Diagnosis
Remote diagnosis with any
Internet-PC worldwide
• with internet browser / internet
explorer
• or with DriveWindow full drive
control via OPC
High Current Solutions
• 12-pulse up to 20,000 A, serial
and parallel
• Hard parallel and sequential
• up to 1,500 V
Protections
Speed feedback monitoring •
Temperature • Overload • Over
speed • Motor stalled • Motor
over current • Motor over voltage
• Field over current • Field over
voltage • Minimum field current
• Zero speed • Armature current
ripple • Mains over- and under
voltage
Integrated IEC 61131-PLC
• Open standard programming
tool ControlBuilder DCS800
• Support of all five IEC-
languages
• Drive-specific function blocks
• Saving of program and source
in Memory Card
• Online debugging and forcing
Approvals
Adaptive Programming
pre-defined drive-specific
function blocks, e.g.
• Free process controller (PI-
Controller)
• I/O- and digital Operations
With control panel or PC-Tool, no
need for additional hardware
Speed Feedback
EMF
Analogue tacho
Encoder
2nd Encoder possible (RTAC)
Communication
Serial communication
• Ethernet • Profibus
• CANopen • DeviceNet
• ControlNet • DDCS
• Modbus
• CS31 • AF100
• Selma2
Industrial IT
©
enabled
DCSLink Peer-to-Peer
• up to 800 kBaud, < 2.5 ms
• Master-Follower
• Armature-fieldconverter
• Free selectable data
3)
600V
2-Q -> 290 A / 590 A
4-Q -> 320 A / 650 A
Unit size 2-Q
rated Current
DCS800-01
4-Q
rated Current
DCS800-02
Supply voltage
[V
AC
]
max. field
current
internal
Dimensions
I
DC
[A] I
DC
[A] 400 525 600 690 800 990 1200 [A
DC
] h x w x d [mm] h x w x d [inch]
D1 20 25
6 370 x 270 x 200 14.56 x 10.65 x 7.90
45 50
65 75
90 100
125 140
D2
180 200
15 370 x 270 x 270 14.56 x 10.65 x 10.65
230 260
D3 315 350
3)
20 459 x 270 x 310 18.07 x 10,65 x 12,25
405 450
470 520
D4 610 680
3)
25 644 x 270 x 345 25.35 x 10.65 x 13.60
740 820
900 1000
D5 900 900 25 1050 x 510 x 410 41.35 x 20.10 x 16.15
1200 1200
1500 1500
2000 2000
1)
1)
D6 1900 1900
external field
35A, 1~/3~
50/60A, 1~
520A, 3~
1750 x 460 x 410 68.90 x 18.15 x 16.15
2050 2050
2500 2500
3000 3000
D7 2050 2050
external field
35A, 1~/3~
50/60A, 1~
520A, 3~
1750 x 760 x 570 68.90 x 29.95 x 22.45
2600 2600
2)
3300 3300
2)
4000 4000
4800 4800
5200 5200
1)
only available as 2-Q drive
2)
on request
Current ratings, dimensions
