ABB DCT880 - Current Ratings; 50 Hz and 60 Hz supply current ratings

13
Current ratings with 50 Hz and 60 Hz supplies see below. The current ratings are based on an ambient
temperature of maximum 40°C and an elevation of maximum 1000 m above mean sea level:
Size
I
[A] (RMS)
Thyristor power controller
400 V / 525 V
Thyristor power controller
690 V
T1
20
DCT880-W0x-0020-04/05
-
35
DCT880-W0x-0035-04/05
DCT880-W0x-0035-07
55
DCT880-W0x-0055-04/05
-
80
DCT880-W0x-0080-04/05
DCT880-W0x-0080-07
100
DCT880-W0x-0100-04/05
DCT880-W0x-0100-07
125
DCT880-W0x-0125-04/05
-
T2
160
DCT880-W0x-0160-04/05
DCT880-W0x-0160-07
200
DCT880-W0x-0200-04/05
DCT880-W02-0200-07
245
DCT880-W0x-0245-04/05
-
T3
325
DCT880-W0x-0325-04/05
-
360
DCT880-W0x-0360-04/05
DCT880-W0x-0360-07
420
DCT880-W0x-0420-04/05
-
T4
550
DCT880-W0x-0550-04/05
-
630
-
DCT880-W0x-0630-07
675
DCT880-W0x-0675-04/05
-
740
DCT880-W0x-0740-04/05
-
T5
890
DCT880-W03-0890-04/05
DCT880-W03-0890-07
960
DCT880-W02-0960-04/05
DCT880-W02-0960-07
Note:
Input current = output current
