ABB DPA UPScale ST200 - Event Log; UPS Data

Modifications reserved
Page 46/79
6
Discharge current.
DISCHARGE CURRENT (A)
00.00
7
Rectifier voltage of all three phases
RECTIFIER VOLTAGE (V)
230 230 230
8
Bypass voltage of all three phases
BYPASS VOLTAGE (V)
230 230 230
9
Output voltage of all three phases
OUTPUT VOLTAGE (V)
230 230 230
10
Output current of all three phases
OUTPUT CURRENT (A)
00.00 00.00 00.00
11
Active output power of all three phases
ACTIVE POWER (KW)
00.00 00.00 00.00
12
Reactive Output power of all three phases
REACTIVE POWER (kVAr)
00.00 00.00 00.00
13
Apparent output power of all three phases
APPARENT POWER (KVA)
00.00 00.00 00.00
14
Output power of all three phases
OUTPUT POWER (%)
00.00 00.00 00.00
15
Battery capacity
BATT. CAPACITY (%)
00.00
16
Battery temperature
(only when the option battery probe is connected.)
BATT. TEMPERATURE
00.00
17
Module temperature
Booster (°C), Inverter (°C)
MODULE TEMP. BST/INV
24.5 28.3
18
End of measurements
NO MORE MEASUREMENTS
6.3.2 Event log
DESCRIPTION LCD-DISPLAY
1
Logging control; a log of the last 64 events is
stored in the power management display.
01 05-10-00
LOAD TO INV.
14-38-59
2
Every stored event is identified with a sequential
number and time stamp.
02 05-10-00
LOAD TO BYP.
14-38-56
3
All events and alarms are indicated with their date
and time of appearance.
03 05-10-00
LOAD OFF
14-37-14
6.3.3 UPS Data
DESCRIPTION LCD-DISPLAY
1
These general UPS data are installed at the
manufacturing plant
UPS SERIAL NUMBER
NW-nnnnn
