7.5.1 DIP switch SW1-6
DIP SWITCH SW1-6 is located on every UPS cabinet. With this switch it is possible to determine the
“position of the cabinet” in a multi-cabinet chain. Define each DPA UPSCale ST S2 cabinet as the
“first”, “middle” (there may be more than one) or the “last” cabinet in the multi-cabinet chain by setting
the DIP switch SW1-6 on each cabinet according to the table below:
1. The “First”,
2. The “Middle” (there may be more than one) and
3. The “Last”
Cabinet in the multi cabinet chain by setting the DIP Switch SW1-6 on each cabinet according to the
Table below:
SWITCH SW1-6
1
ST
UPS Other UPS Last UPS Single UPS
