ABB EasyLine EL3020 - Dimensional Drawings

36 EasyLine EL3000 Series Commissioning Instructions
Dimensional Drawings
19-inch Case (Model EL3020)
Dimensions in mm
19-inch Case (Model EL3020 with Magnos27)
Dimensions in mm
NOTE
Only the front view of the housing with its height differing from the
standard dimension is depicted in this dimensional drawing. Refer to the
dimensional drawing above for other views and dimensions of the
housing.
