Electrical connections
22 OI/PME/LME/EAN823/EBN853/EBN861-EN
4.4 Terminal connection diagrams
4.4.1 Integrated electronic unit AI
4.4.1.1 Analog / digital
Important (Notice)
The power and signal cables are connected by universal plug to the integrated actuator
electronic unit.
Fig. 12
4.4.1.2 PROFIBUS DP
M00250
DO1
endp. 0%
DO2
endp. 100%
mains
113
L
N
B1 B2A1 A2
S1
ext. fuse
Bus in
bus
connection
Han 24E
plug
Bus out
Contrac actuator
(plug)
bus
termination
green
red
green
red
Screen at both ends up
to the sub distribution board.
One-sided screening
in further wiring possible.
21
18
19 20
Fig. 13
