ABB EBN853 - 9 Specifications

Specifications
38 OI/PME/LME/EAN823/EBN853/EBN861-EN
9 Specifications
Power Electronic Unit EAN823 (Contrac)
Ingress protection IP 66 acc. to IEC 60529 / EN 60529
NEMA 4X acc. to CAN/CSA22.2 No. 94
Humidity
≤ 95% annual average; condensation not permitted
Ambient temperature -25 … 55 °C (-15 … 130 °F)
Transport and storage temperature -25 ... 70 °C (-15 ... 160 °F)
Long-term storage temperature -25 ... 40 °C (-15 ... 105 °F)
Installation position at vertical support, cable gland on the left side
Coating Dual component epoxy (RAL 9005; black)
Cable between actuator and electronic unit
Optional 5 m (16 ft), 10 m (32 ft) or 20 m (65 ft) with plug for connection to the actuator; max.
cable length between actuator and electronic unit: 30 m (98 ft)
Weight; approx. 10 kg (22 lbs)
Supply voltage 115 V AC (94 … 130 V) or 230 V AC (190 … 260 V); 47.5 … 63 Hz; 1Ph
l
max
.
at 115V l
max
.
. at 230V
LME620-AI 1.0 A 0.5 A
Current at electronic unit [A] (115 V AC /
230 V AC)
PME120 1.0 A 0.5 A
LME620-AI 1.4 A 0.7 A
Actuators for low temperature design
PME120 1.4 A 0.7 A
l
pos.
(115V + 230 V)
approx. 40 … 50% of
l
max
.
External fuse 16 A; time-lag
Power Electronic Unit EBN853 (Contrac)
Ingress protection IP 66 acc. to IEC 60529 / EN 60529
NEMA 4X acc. to CAN/CSA22.2 No. 94
Humidity
≤ 95% annual average; condensation not permitted
Ambient temperature -25 … 55 °C (-15 … 130 °F)
Transport and storage temperature -25 ... 70 °C (-15 ... 160 °F)
Long-term storage temperature -25 ... 40 °C (-15 ... 105 °F)
Installation position at vertical support, cable gland at the left side
Coating 2-layer component epoxy (RAL 9005, black)
Cable between actuator and electronic unit
Optional 5 m (16 ft), 10 m (32 ft) or 20 m (65 ft) with plug for connection to the actuator; max.
cable length between actuator and electronic unit: 100 m (328 ft)
Weight; approx. 11 kg (24 lbs)
Supply voltage 115 V AC (94 … 130 V) or 230 V AC (190 … 260 V); 47.5 … 63 Hz; 1Ph
l
max
.
at 115V l
max
.
. at 230V
RHD250-10 1.8 A 0.9 A
RHD500-10 2.2 A 1.1 A
RHD800-10 5.0 A 2.5 A
RHD1250-12 5.0 A 2.5 A
RHD2500-25 5.0 A 2.5 A
RHD4000-40 5.8 A 2.7 A
RHD8000-80 5.0 A 2.5 A
RSD10-5.0 2.2 A 1.1 A
RSD10-10.0 3.6 A 1.8 A
RSD20-5.0 3.6 A 1.8 A
RSD20-7.5 4.8 A 2.4 A
RSD50-3.0 5.0 A 2.5 A
Current at electronic unit [A] (115 V AC /
230 V AC)
RSD100-1.5 5.0 A 2.5 A
l
pos.
(115V + 230 V)
approx. 40 … 50% of
l
max
.
External fuse 16 A; time-lag
