INSTRUCTION HANDBOOK
89
Pull out the 4 auxiliary contacts from the 4
91
Manually remove the terminal box case.
90
By means of the cross screwdriver unscrew the
3 screws fixing the terminal box case to the
circuit breaker main structure.
92
Manually pull and remove the connector
located in the right part of the terminal box
case.
88
By means of the flat screwdriver separate the
87
Push the flat srewdriver in the direction
indicated by the arrow and after manually
remove the microswitch assembly.
