pH / Redox (ORP) transmitter 7 Operator Pages and Menus
54 OI/APA592–EN Rev. E
7.3 Parameters
7.3.1 Easy Setup
Users with Advanced level access have read / write privileges
to the parameters listed.
Users with Standard and Read Only access have read-only
privileges to parameters at Easy Setup level.
Easy Setup Parameters
Parameter Description
Tx
Ty p e
Analyzer Type Selects the measurement type:
 pH
 ORP
 pION
 Ion Conc
All
pH Sensor Type Selects the sensor type used for measurement:
 Glass
 Antimony
 Custom
pH
Isopotential Pt. (Isopotential Point)
Adjustable range –20 to 20 pH. Default = 7 pH.
Enabled when pH Sensor Type = Custom.
pH
Asymmetric Pt. (Asymmetric Potential)
Adjustable range –2000 to 2000 mV. Default = 0 mV
Enabled when pH Sensor Type = Custom.
PH
Valence Ion valence selection: -3, -2, -1, 1, 2, or 3.
The valence determines the millivolt change per decade of concentration.
Ion
Conc
Magnitudes The number of magnitudes ranging from 1 to 3 that defines the ion
concentration output.
Ion
Conc
End Mag The ion concentration state functions by associating an end millivolt value to
an end magnitude value.
The end magnitude value can be set to 10, 100 or 1000.
Ion
Conc
End mV The end millivolt value associated with the end magnitude value. Ion
Conc
PV Units Sets the process value units (%, ppm, µg/l, ppb, mg/l). Ion
Conc
Temp. unit (Temperature Units)
Sets the temperature unit (°C or °F) applied to all transmitter temperature
parameters and values.
All
1
Menu
Exit
Select
Easy Setup
