pH / Redox (ORP) transmitter 7 Operator Pages and Menus
OI/APA592–EN Rev. E 63
7.3.3 Device Setup
Used to set the sensor / sensor input, run temperature sensor
recognition and obtain transmitter information.
Note. Required access level = Advanced.
Device Setup Parameters
Parameter Description
Tx
Ty p e
Sensor Type
Analyzer Type Sets the analyzer type:
 pH
 ORP
 pION
 Ion Conc
All
pH Sensor Type Selects the type of sensor used for measurement:
 Glass
 Antimony
 Custom
pH
Isopotential Pt. (Isopotential Point)
Enabled when pH Sensor Type = Custom.
Adjustable range –20 to 20 pH. Default = 7 pH.
Enabled when pH Sensor Type = Custom.
Asymmetric Pt (Asymmetric Potential)
Adjustable range –2000 to 2000 mV. Default = 0 mV
Enabled when pH Sensor Type = Custom.
Valence Ion valence selection of either –3, –2, –1, 1, 2, or 3.
The valence determines the millivolt change per decade of concentration.
Ion
Conc
Magnitudes The number of magnitudes ranging from 1 to 3 that defines the ion
concentration output.
End Mag The ion concentration state functions by associating an end millivolt value to
an end magnitude value. The end magnitude value can be set to 10, 100 or
1000.
End mV The end millivolt value associated with the end magnitude value.
Sensor Diag Turns sensor diagnostics on (Yes) or off (No).
All
Reference Imp. Limit A reference impedance value above this limit triggers a diagnostic error for
high-reference impedance.
Adjustable range 1 to 1000 K. Default = 50 K.
Limit enabled when Sensor Diag = Yes.
3
Menu
Exit
Select
Device Setup
