Operation Manual / TPR56-F + TPR61-F
4 Operation / 4.4 Speed measurement
© Copyright 2018 . All rights reserved. HZTL2490_EN Revision D May 2018
4.4 Speed measurement
A speed measuring system permits continuous monitoring of the tur-
bocharger speed.
CAUTION
Do not use cables as a climbing aid
If you pull the speed measurement cables too hard, contacts can be
pulled out.
u Do not tension the speed measurement cables.
Part number Description
42047 Screw plug
86505 Speed sensor
86515 Cable connector for 86505
86526 F/I converter
86528 Tachometer
Page 39 / 79
