Operation Manual / TPR56-F + TPR61-F
11 Spare parts / 11.1 Ordering spare parts
© Copyright 2018 . All rights reserved. HZTL2490_EN Revision D May 2018
11 Spare parts
11.1 Ordering spare parts
When making inquiries or ordering spare parts, the following data must
be specified:
¡ Turbocharger type
¡ Serial number (HT……)
¡ Designation and part number.
Spare parts can be ordered from an official ABB Turbocharging service
station.
u If different design versions have not been taken into consideration in
this document, please contact an ABB Turbocharging service station.
CAUTION
Storage of spare parts
All spare parts ordered with the turbocharger must be kept complete
and ready for use.
u Parts showing signs of rust should be carefully cleaned and greased.
u Dispose of replaced and unusable parts in a professional and environ-
mentally compatible way.
Required customer spare part set (97070)
Quantity Description Part number
15 Hexagon-head screw 42059 / 42064 / 61044
61056 / 61059
15 Verbus Ripp® washer 42058 / 42063 / 61043
61057 / 61058
3 Hexagon nut 61037
1 Gasket 42041
2 Gasket 42045
1 O-ring 42012
2 O-ring 77005 / 77006
1 O-ring 86506
