Operation Manual / TPR56-F + TPR61-F
8 Disassembly and assembly / 8.8 Table of tightening torques
© Copyright 2018 . All rights reserved. HZTL2490_EN Revision D May 2018
Tightening torques [Nm]
Item Part number TPR56-F TPR61-F
1 72027 M10
30
M12
50
2 61036
72026
M10
20
M12
30
3 72002 M6
10
M8
25
4 61044
61056
61059
M10
80
M12
130
5 61064 M10
35
M12
60
6 42059
42064
M10
80
M12
130
7 86505
If provided
M18x1.5
150
M18x1.5
150
8 61037 M10
50
M12
80
9 61090 M10
10
M12
10
