Operation Manual / TPR56-F + TPR61-F
11 Spare parts / 11.2 View of turbocharger with part numbers
© Copyright 2018 . All rights reserved. HZTL2490_EN Revision D May 2018
Part number Description
– Cartridge group
42012 (in customer spare part set) O-ring
51001 Gas inlet casing
51012 Segment
56001 Nozzle ring
61001 Gas outlet casing
61037 (in customer spare part set) Hexagon nut
61043 (in customer spare part set) Verbus Ripp® washer
61044 (in customer spare part set) Hexagon-head screw
61056 (in customer spare part set) Hexagon-head screw
61057 (in customer spare part set) Verbus Ripp® washer
61058 (in customer spare part set) Verbus Ripp® washer
61059 (in customer spare part set) Hexagon-head screw
63000 Turbine diffuser
72000 Compressor casing
72018 Washer
72027 Hexagon nut
77000 Wall insert
77005 (in customer spare part set) O-ring
77006 (in customer spare part set) O-ring
79000 Diffuser
81000 Filter silencer
82000 Radial air suction branch
82000 Axial air suction branch
