Document: v0.6 / Document No.: 6AGA000008-0102-EN | Date: 22-05-2019 Page 10 of 23
2 Description of the product
2.1 Overview of the system
A. Charge cabinet 100-150kW
B. Depot charge boxes (up to 3 per charger with sequential charging)
2.2 Charge cabinet
A. Door
B. Door handle / lock
C. 3G Antenna
D. Air inlets (also on the left and back side)
E. Air outlet
The Power Cabinet has air inlets (D) and an air outlet (E) to control
the temperature inside the cabinet. Do not install or place any ob-
jects near or against these air inlets and outlet. If necessary, take
precautions to prevent snow or any other objects from blocking the
air inlets and outlet.
