IM300 Intelligent Power Monitoring Instrument
99
factor of
phase B
phase B
phase B
phase B
phase B
31
30
29
28
27
26
25
24
Low
power
factor of
phase C
Retain
Retain
Low
voltage of
phase C
Over
voltage of
phase C
Over
current of
phase C
The zero
current of
phase C
Retain
Year bytes
：
Range 00
～
99 represents
（
2000
～
2099year
）；
Month bytes：Range 01～12 represents（01～12month）；
Day bytes
：
Range 01
～
31 represents
（
01
～
31day
）；
Hour bytes：Range 00～23 represents（00～23hour）；
Minute bytes
：
Range 00
～
59 represents
（
00
～
59minute
）；
Millisecond high byte & second bytes ： BIT7 and BIT6 represent
millisecond high, from0 to 3; BIT5~BIT0 represent second, from 0 to
59.
Millisecond low bytes
：
Range 0
～
255
；
(Milliseconds with millisecond
High byte, Range 0 to 999).
Format for example: (the length of the SOE data structure is 8, Described time
is 2002-3-25 10:32:24 300 millisecond. Status of the third remote signal change
from ON to OFF. )
Field Name
Example(Hex)
Slave Address
2A
Function
55
Byte Count
09
SOE Status
00
SOE0-Information
C2
SOE0-Year
02
SOE0-Month
03
SOE0-Day
19
SOE0-hour
0A
