The low bits of register 40802 denote second，range: 0～59.
 Register of electric parameters MAX/MIN value occurrence time――Register
41060,41061 and 41062:
The high bits of register 41060 denote year, range: 0
～
99;
The low bits of register 41060 denote month，range: 1～12；
The high bits of register 41061 denote day, range: 1
～
31
；
The low bits of register 41061 denote hour，range: 0～23；
The high bits of register 41062 denote minute
，
range: 0
～
59
；
The low bits of register 41062 denote second，range: 0～59.
 Register of quick remote signal inquiry - Register 42000:
Bit site
7
6
5
4
3
2
1
0
42000
high
byte
0
0
0
0
DI4
DI3
DI2
DI1
42000
low
byte
Low
power
factor of
phase A
Low
frequenc
y of
phase A
Over
frequenc
y of
phase A
low
voltage of
phase A
Over
voltage of
phase A
Over
current of
phase A
The zero
current of
phase A
Over
ground
current
alarm
42001hi
gh byte
Low
power
factor of
phase B
Retain
Retain
Low
voltage of
phase B
Over
voltage of
phase B
Over
current
of phase
B
The zero
current of
phase B
Retain
42001
low
byte
Low
power
factor of
phase C
Retain
Retain
Low
voltage of
phase C
Over
voltage of
phase C
Over
current of
phase C
The zero
current of
phase C
Retain
4.4. SOE Communication Format Description
The function code of SOE inquiry is 55H and alarm SOE inquiry is 56H
which is the extension part of MODBUS RTU protocol. These function codes are
used to ask SOE in the nominated address and do not support broadcasting command.
The communication format is as follows:
