IM300 Intelligent Power Monitoring Instrument
the 1th quadrant total reactive energy
Top of the screen shows "total"and "+ Eq" word.
See in fig 3.2.50: -E
q-1
＝11.1kvarh
Screen 30 to screen 33: Display the absolute value of the 1th quadrant
reactive energy at sharp,peak, shoulder or off-peak rate
“Eq-1” displayed on the top.the screen display is similar to screen 29.
Screen 34: Display the absolute value of the 4th quadrant total reactive
energy
“Eq-4” displayed on the top, the screen display is similar to screen 29.
Screen 35 to screen 38: Display the absolute value of the 4th quadrant
reactive energy at sharp,peak, shoulder or off-peak rate
“Eq-4” displayed on the top, the screen display is similar to screen 29.
Screen 39: Display the absolute value of the 2th quadrant total reactive
energy
“Eq-2” displayed on the top, the screen display is similar to screen 29.
Screen 40 to screen 43: Display the absolute value of the 2th quadrant
reactive energy at sharp,peak, shoulder or off-peak rate
“Eq-2” displayed on the top.the screen display is similar to screen 29.
Screen 44:Display the absolute value of the 3th quadrant total reactive
energy
“Eq-3” displayed on the top, the screen display is similar to screen 29.
