IM300 Intelligent Power Monitoring Instrument
66
40065
RW
Electrical parameters of
the maximum and
minimum range of
statistics
1~1440min
Defaults：10
1
40067
RW
Direction of CT wiring
Defaults ：
0x00000000
2(Write
continu
ously)
40070
RW
Telemetry wiring mode
1~5
Defaults
：
1
1
40072
RW
PT primary voltage
rating
100~35000V
Defaults：
220/220
2(Write
continu
ously)
40073
RW
PT secondary voltage
rating
100
～
220V
40075
RW
bit14-bit0 represents CT
primary current rating
bit15 = 0/1 indicates the
secondary is 5A/1A
Primary
current
rating：
1～9999A
Defaults：
0x1388
（5000：5）
1
40077
RW
bit 14-bit 0 indicates
zero-sequence CT
primary current rating
bit15 = 0/1 indicates the
secondary is 5A /1A
Primary
current
rating:
1
～
9999A
Defaults：
0x1388
（5000：5）
1
40081
RW
Relay output settings
1～2
Defaults：1
1
40085
AO related electrical
parameter range
2（Write
continuo
usly
）
40086
AO related electrical
parameter types
40088
RW
Pulse length of relay
output
50
～
20000
Defaults
：
2000，Unit：
ms
1
