IM300 Intelligent Power Monitoring Instrument
89
42001
RO
DI 2
1
42002
RO
Current Ia
1
42003
RO
Current Ib
1
42004
RO
Current Ic
1
42005
RO
Zero-sequence current In
1
42006
RO
Line voltage Uab
1
42007
RO
Line voltage Ubc
1
42008
RO
Line voltage Uca
1
42009
RO
Phase voltage Uan (valid in 3-phase,4-wire system)
1
42010
RO
Phase voltage Ubn (valid in 3-phase,4-wire system)
1
42011
RO
Phase voltage Ucn (valid in 3-phase,4-wire system)
1
42012
RO
Frequency（F）
1
42013
RO
Total active Power（W）
1
42014
RO
Total reactive power（Q）
1
42015
RO
Total apparent power（S）
1
42016
RO
Total power factor
（
PF
）
1
42017
RO
Total active energy
（
Ep
）
2
42019
RO
Total reactive energy（Eq）
2
42021
RO
Retention
2
42023
RO
Retention
2
Note 1: In the 3-phase 3-wire system, the data in 42009～40011 are
invalid and value is 0.
Note 2: The correspondence between the above data (Ai) and the
actual value is:
Voltage: U = (Ai / 10) × (PT1 / PT2), Ai is an unsigned integer, unit:V.
Current: I = (Ai / 1000) × (CT1 / CT2), Ai is an unsigned integer,
unit:A.
Zero-sequence current: In = (Ai / 1000) × (CT01 / CT02), Ai is an
unsigned integer, unit:A.
Active power: P = Ai × (PT1 / PT2) × (CT1 / CT2), Ai signed integers,
unit:W.
