IM300 Intelligent Power Monitoring Instrument
92
Bit7
Retention
0
Bit8
Retention
0
Bit9
Retention
0
Bit10
Retention
0
Bit11
Retention
0
Bit12
Retention
0
Bit13
Retention
0
Bit14
Retention
0
Bit15
Retention
0
 Sub-station setting register (40055):
Address
Definitions
Default value
Bit0
Clear hard-SOE
0
Bit1
Limit alarm reset
0
Bit2
Clear all the energy
0
Bit3
Clear soft-SOE
0
Bit4
Retention
0
Bit5
Retention
0
Bit6
Retention
0
Bit7
Retention
0
Bit8
Freeze all the energy
0
Bit9
Unfreeze all the energy
0
Bit10
Retention
0
Bit11
Clear the demand
0
Bit12
Retention
0
Bit13
Retention
0
Bit14
MAX/MIN value reset
0
Bit15
Forced reset
0
Note: It needn’t to return messages when broadcast freeze or unfreeze. After
sending the freeze command by the upper computer, all of the reading
energy values are equal to the electric accumulated value of the frozen
