IM300 Intelligent Power Monitoring Instrument
91
 System time - millisecond register (40023): from 0 to 999.
 Communication address (40030): from 1 to 254, 0 and 255 are reserved as
broadcast address. The default is 254.
 Communication baud rate (BAUD) (40032): 1 ~ 5 respectively baud rate,
as follows:
Baud rate code
Explanation
1
1200 bps
2
2400 bps
3
4800 bps
4
9600 bps
5
19200 bps
 Check mode (PARITY) (40034): 0 to 3, representing the check mode, the
following table:
Check mode Code
Explanation
0
No parity check, 2 end bits
1
Odd check, 1end bit
2
Even check, 1 end bit
3
No parity check, 1 end bit
 Sub-station status register (40050):
Address
Definitions
Default value
Remark
Bit0
DI change sign
0（None）
Cleared after DI inquiry
Bit1
Existence sign of
hard-SOE
0（None）
Cleared after all
communication SOE inquiry
Bit2
Protection action sign
0（None）
Cleared after communication
inquiry or reset action
Bit3
Sign of checking time
1
（
Time was not
ticked when
power-on）
Cleared after remote time tick
Bit4
Existence sign of
soft-SOE
0（None）
Cleared after all
communication SOE inquiry
Bit5
Retention
0
Bit6
Retention
0
