58 User Guide | OI-LLT100-EN Rev. D
LLT100
Laser level transmitter
Specifications
Dust tube
Base plate diameter 165 mm (6.5 in.) mounts on LLT100 standard flange
Length 257 mm (10.1 in.)
Material Epoxy powder-coated stainless steel
Gasket material Black compressible Buna-N rubber durometer rating shore 60A
Function Static air space prevents dust buildup, can be purged.
Offset from hot process interface to allow convection cooling, can be purged.
Purge
Purge air flow Must be oil free dry air
recommended flow between 0.5 and 4 l/minute
maximum inlet pressure 5.5 bar (80 psi)
Purge fitting
1
∕8 NPT
Flange reducer
Side A 2 in. ANSI class 150 raised face flange DN50 PN40 raised face flange
Side B raised face 3 in. ANSI
class 150
4 in. ANSI
class 150
6 in. ANSI
class 150
DN80 PN40 DN100 PN40 DN150 PN40
Side B flat face 3 in. ANSI
class 150
4 in. ANSI
class 150
6 in. ANSI
class 150
DN80 PN40 DN100 PN40 DN150 PN40
Material 304 Stainless steel
Adjustable swivel mount
Outer diameter 210 mm (8.3 in.)
Mounting bolt pattern 3 bolt holes, 10 mm (0.4 in.) diameter
Tilt angle for aiming Continuously adjustable from 0° to 6°
Material Aluminum
Adjustable pivot bracket
Overall dimensions 185mm (7.3in.) × 249mm (9.8in.) × 55mm (2.2in.)
Opening diameter 60 mm (2.4 in.)
Mounting plate thickness 5 mm (0.2 in.)
Mounting bolt 4 × HHCS 5/8-11 × 2 SS, + 8 × Washers + 2 × lock washers + 4 × nuts, bolt hole 8 × 18 mm (0.7 in.)
Reflector
Function Reflective panel for positioning applications up to 200 m
Size 90 cm × 90 cm (36 in. × 36 in.)
Material Aluminum with reflective paint
Cable glands and stopping plugs
Description Ex cable glands with ½ in. NPT or M20 thread size
Ex C1/D1 cable glands with ½ in. NPT or M20 thread size
Demo kit
Description Rugged carrying case with LLT100, dust tube, battery pack, laser pointer tool
External laser pointer tool
Function Laser pointer accessory used for targeting and aiming purpose.
Pointing laser 650 nm wavelength
Less than 1mW output power
Pointing laser safety Class 2M
