26 User Guide
7 Connect one end of the coaxial cable to the botton of the head-coupler adapter (see Figure 16).
NOTICE
When connecting either end of the coaxial cable, we strongly suggest the use of a wrench
or pliers.
The coaxiable cable bend radius shall not be less than 150 mm (6 in).
—
Figure 16 Connecting the coaxial cable to the head-coupler adapter
Coaxial cable
8 Connect the other end of the coaxial cable to the top of the coupler (see Figure 17).
—
Figure 17 Connecting the coaxial cable to the top of the coupler
