快速安装指南
- MicroFlex e150 69
RS485 通信协议
RS485 接口用于连接串行设备,如操作面板和可编程逻辑控制器
PLC)。
输入 / 输出
附加 24 V DC 12-30 V DC)通用数字输入和输出。
紧固力矩
启动
参加手册 MN1961WCN
Pin
2-
线 4- 线
1 TXA(+) / RXA(+) TXA(+)
2 TXB(-) / RXB(-) TXB(-)
3GND GND
4
7V
输出 7V 输出
5 (NC) RXA(+)
6 (NC) RXB(-)
N·m (lbf·in)
端子板接头 X1 X2
OPT1
0.5 - 0.6 (4.4 - 5.3)
X6
1
OPT1
DIN4
DIN5
CREF1
Shield
DIN6
DIN8
DIN7
DIN9
CREF0
USRV+0
DOUT3
DOUT5
DOUT4
DOUT6
