Section 3 Interface Modules
Removal
For proper vibration and chock performance ABB recommends standard top-hat
DIN-rail TH 35-15 according to EN 60715.
Press down the support at the back of the unit using a screwdriver as shown in
Figure 11.
Wall Mounting
This unit can also be wall-mounted as shown in “Figure 12. Wall Mounting the
Unit”.
Figure 10. Mounting, 35 mm DIN-rail
Mounting
The unit can be mounted on a 35 mm DIN-rail, which is horizontally mounted
inside an apparatus cabinet, or similar. Snap on mounting as shown in “Figure 10.
Mounting, 35 mm DIN-rail”.
