ABB NE870 - Type Tests and Environmental Conditions

3BSE08315932
Section 3 Interface Modules
Type Tests and Environmental Conditions
Environmental
phenomena
Test Description Test levels
ESD EN 61000-4-2 Enclosure contact ±6 kV
Enclosure air ±8 kV
RF eld AM
modulated
IEC 61000-4-3 Enclosure 20 V/m 80% AM (1 kHz), 80–2700 MHz
10V/m 80% AM (1 kHz), 2700-6000 MHz
Fast transients EN 61000-4-4 Power port ±2 kV
Signal ports ±2 kV
Surge EN 61000-4-5 Power port ± 2 kV line to earth, ± 1 kV line to line
Signal ports ± 2 kV line to earth, ± 1 kV line to line
RF conducted EN 61000-4-6 Power port 10 V 80% AM (1 kHz), 0.15–80 MHz
Signal ports 10 V 80% AM (1 kHz), 0.15–80 MHz
Power frequency
magnetic eld
EN 61000-4-8 Enclosure 300 A/m 0, 16.7, 50, 60 Hz
Pulsed magnetic
eld
EN 61000-4-9 Enclosure 300 A/m
Radiated emission CISPR 16-2-3 Enclosure Class B
ANSI C63.4
(FCC part 15)
Enclosure Class B, 30 - 6500 MHz
Conducted
emission
CISPR 16-2-1 DC power ports
Telecommunication
ports Class B
Class B
