NETA-21 remote monitoring tool 5
1 X1 10…30 V DC – power supply input
2 X2 EIA-232 port
• 9-pin D-sub male type connector X2
• EIA-232 level interface for a modem
3 X3 EIA-485 port
• 4-pin detachable screw type connector X3
• EIA-485 level interface for a Modbus network
4 Termination jumpers for the link connected to X3
5 X11 AC/DC 24V – secondary power supply input
