5SAFETY INFORMATION, INSTALLATION INSTRUCTIONS
—
2. Installation instructions — normal,
heavy and extreme duty panels
The following information is provided for your
reference during the installation of PSTX soft
starter normal and heavy duty panels. Please note
that all equipment must be installed in accordance
with the applicable NFPA 70 (National Electrical
Code, NEC) edition and local building codes
(or similar). PSTX soft starter normal, heavy and
extreme duty panels are built to the UL 508A
industrial control panel standard. This document
provides information pertaining to: inspections,
environment, installation and wiring. The PSTX
user’s manual (1SFC132082M9901) and the PSTX
soft starter panel operating instructions contained
in this document offer additional information and
will be referenced throughout.
Initial inspection
After unpacking your soft starter panel, inspect
it for damage that may have occurred during
shipment.
If any damage is found, please report it to the
distributor from which the panel was purchased.
Care should be taken when unpacking the panel;
improper use of tools could damage equipment.
Preparing for installation
Remove and discard desiccant/drying/silica
packs if included.
Before you begin to install the PSTX soft starter
panel, make sure the proper equipment for lifting
is available. Refer to the appropriate outline
drawing for the dimensions, estimated weight
and required clearances for installation. Refer to
the rating label on back of the cover to verify that
the received product matches the ordered unit
and verify the product listing/marking label.
Improper lifting of enclosure could result
in a fatal or serious injury.
Review the layout and elementary diagrams before
starting to wire your soft starter panel. Care
should be taken when unpacking the panel;
improper use of tools could damage equipment.
Enclosure panel doors can swing more than
90 degrees, and there are no stops to inhibit
the door from hitting equipment located next
to the panel. This could result in damage to
door-mounted switches and indicator lights.
Environment
PSTX soft starter normal and heavy duty panels
are available in enclosures rated NEMA Type 1, 12
3R and 4. The environment must be totally free
from flammable or combustible vapors and/
or dust.
The environments for NEMA Type 1 enclosures shall
be indoors where the following condition may
exist: falling dirt.
The environments for NEMA Type 12 enclosures
shall be indoors where the following conditions
may exist: falling dirt, circulating dust and/or
non-corrosive dripping liquids.
The environments for NEMA Type 3R enclosures
shall be indoors or outdoors where the following
conditions may exist: falling dirt, rain, sleet, snow
and external formation of ice on the enclosure.
