7.17.1.5 Heat sink over temperature
The sofstarter measures the heat sink temperature. If
the temperature gets to high this fault is signaled. The
purpose of the heat sink is to cool the thyristors.
Heat sink over temperature fault is configured with the
following parameters:
Parameter Description Setting range Default value
25.09 Heat sink over temp out
Specifies the Event groups this
fault belongs to.
Eventgroup 0 ... 6 1
25.10 Heat sink over temp op
Sets the operation of this fault.
Stop manual, Stop
auto
Stop manual
7.17.1.6 Unspecified fault
This fault is a grouping of several internal faults that are
quite unlikely and does not need to specified as individual
faults.
Unspecified fault is configured with the following
parameters:
Parameter Description Setting range Default value
25.11 Unspecified fault out
Specifies the Event groups this
fault belongs to.
Eventgroup 0 .. 6 1
25.12 Unspecified fault op
Set the operation of this fault.
Stop manual, Stop
auto
Stop manual
