Parameter
number
Description Setting range Number of
decimal
Fieldbus
ID
Default value Actual
setting
13 Protections list 1
13.01 EOL mode Normal, Dual 0 55 Normal
13.02 EOL class 10A, 10, 20, 30 0 56 10
13.03 EOL dual class 10A, 10, 20, 30 0 57 10A
13.04 EOL out 0 ... 127 0 84 0000010
13.05 EOL operation Off, Stop-Manual, Stop-Automatic, Indication 0 0 Stop-Manual
13.06 Locked rotor level 0.5 ... 8.0 x
I
e
1 54 4.0 x I
e
13.07 Locked rotor trip time 0.2 ... 10.0 s 2 53 1.00 s
13.08 Locked rotor delay time 1.0 ... 30.0 s 2 52 5.00 s
13.09 Locked rotor out 0 ... 127 0 85 0000010
13.10 Locked rotor op Off, Stop-Manual, Stop-Automatic, Indication 0 0 Off
13.11 Max no of starts per hour 1 ... 100 0 0 6
13.12 Max no of starts per hour
out
0 ... 127 0 0 0000010
13.13 Max no of starts per hour
op
Off, Stop-Manual, Stop-Automatic, Indication 0 0 Off
14 Protections list 2
14.01 Curr underload level 0.3 ... 0.9 x
I
e
1 0 0.3 x I
e
14.02 Curr underload trip time
0 ... 10 s 0 0 1 s
14.03 Curr underload delay time 0 ... 10 s 0 0 10 s
14.04 Curr underload out 0 ... 127 0 87 0000010
14.05 Curr underload op Off, Stop-Manual, Stop-Automatic, Indication 0 0 Off
14.06 Pwr factor underload level 0.0 ... 1.0 2 0 0.70
14.07 Pwr factor underload trip
time
0 ... 10 s 0 0 1 s
14.08 Pwr factor underload delay
time
0 ... 30 s 0 0 10 s
14.09 Pwr factor underload out 0 ... 127 0 86 0000010
14.10 Pwr factor underload op Off, Stop-Manual, Stop-Automatic, Indication 0 0 Off
14.11 Curr imb level 10 ... 80 % 0 61 80 %
14.12 Curr imb trip time 1 ... 30 s 0 63 10 s
14.13 Curr imb delay time 1 ... 30 s 0 62 30 s
14.14 Curr imb out 0 ... 127 0 64 0000010
14.15 Curr imb operation Off, Stop-Manual, Stop-Automatic, Indication 0 60 Off
15 Protections list 3
15.01 Over voltage level 170 ... 850 V 0 67 850 V
15.02 Over voltage trip time 0.1 ... 100.0 s 1 65 1.0 s
15.03 Over voltage out 0 ... 127 0 68 0000010
15.04 Over voltage op Off, Stop-Manual, Stop-Automatic, Indication 0 66 Off
15.05 Under voltage level 170 ... 850 V 0 71 170 V
15.06 Under voltage trip time 0.1 ... 100.0 s 1 69 1.0 s
15.07 Under voltage op Off, Stop-Manual, Stop-Automatic, Indication 0 70 Off
15.08 Under voltage out 0 ... 127 0 72 0000010
15.09 Voltage imb level 1 ... 100 % 0 77 10 %
15.10 Voltage imb out 0 ... 127 0 78 0000010
15.11 Voltage imb op Off, Stop-Manual, Stop-Automatic, Indication 0 76 Off
16 Protections list 4
16.01 Phase rev out 0 ... 127 0 89 0000010
16.02 Phase rev operation Off, Stop-Manual, Stop-Automatic, Indication 0 0 Off
16.03 Freq range lower trip lvl 40 ... 72 Hz 0 0 45 Hz
16.04 Freq range upper trip lvl 40 ... 72 Hz 0 0 66 Hz
16.05 Freq range trip time 0.0 ... 60.0 s 1 0 1.0 s
16.06 Freq range out 0 ... 127 0 91 0000010
16.07 Freq range operation Off, Stop-Manual, Stop-Automatic, Indication 0 0 Off
16.08 By-pass open out 0 ... 127 0 95 0000010
16.09 By-pass open operation Off, Stop-Manual, Stop-Automatic, Indication 0 0 Off
7
