Parameter
number
Description Setting range Number of
decimal
Fieldbus
ID
Default value Actual
setting
16 Protections list 4
16.10 Voltage outputs out 0 ... 127 0 82 0000010
16.11 Voltage outputs op Off, Stop-Manual, Stop-Automatic, Indication 0 81 Off
17 Protections list 5
17.01 PTC out 0 ... 127 0 88 0000010
17.02 PTC op Off, Stop-Manual, Stop-Automatic, Indication 0 0 Off
17.03 PT100 2wire res
0...100.0Ω 1 0 100.0Ω
17.04 PT100 trip temp -50 ... 250 °C 0 0 60 °C
17.05 PT100 reset temp -50 ... 250 °C 0 0 40 °C
17.06 PT100 out 0 ... 127 0 98 0000010
17.07 PT100 op Off, Stop-Manual, Stop-Automatic, Indication 0 0 Off
18 Protections list 6
18.01 User defined DI status Active low, Active high 0 0 Active high
18.02 User defined trip time 0.0 ... 60.0 s 1 0 1.0 s
18.03 User defined out 0 ... 127 0 90 0000010
18.04 User defined op Off, Stop-Manual, Stop-Automatic, Indication 0 0 Off
18.05 Earth fault trip time 0.1 ... 1.0 s 1 73 0.5 s
18.06 Earth fault out 0 ... 127 0 75 0000010
18.07 Earth fault op Off, Stop-Manual, Stop-Automatic, Indication 0 74 Off
18.08 Too long curr lim trip time 1 ... 600 s 0 0 10 s
18.09 Too long curr lim out 0 ... 127 0 0 0000010
18.10 Too long curr lim op Off, Stop-Manual, Stop-Automatic, Indication.
Fast ramp
0 0 Off
19 Protections list 7
19.01 HMI failure out 0 ... 127 0 100 0000010
19.02 HMI failure op Off, Stop-Manual, Stop-Automatic, Indication,
Switch of HMI control
0 0 Off
19.03 Fieldbus failure out 0 ... 127 0 97 0000010
19.04 Fieldbus failure op Off, Stop-Manual, Stop-Automatic, Indication,
Switch to I/O control
0 0 Off
19.05 Ext IO failure trip time 300 ... 30000 ms 0 - 1000 ms
19.06 Ext IO failure out 0 ... 127 0 99 0000010
19.07 Ext IO failure op Off, Stop-Manual, Stop-Automatic, Indication 0 0 Off
20 Warnings list 1
20.01 EOL level 40.0 ... 99.0 % 1 181 90.0 %
20.02 EOL out 0 ... 127 0 123 0000100
20.03 EOL warning On / Off 0 182 Off
20.04 Locked rotor level 0.2 ... 10.0 x
I
e
1 0 3.0 x I
e
20.05 Locked rotor init time 1.0 ... 30.0 s 1 - 1.0 s
20.06 Locked rotor out 0 ... 127 0 125 0000100
20.07 Locked rotor On / Off 0 0 Off
20.08 Thyristor OL out 0 ... 127 0 124 0000100
20.09 Thyristor OL On / Off 0 122 Off
21 Warnings list 2
21.01 Curr underload level 0.4 ... 1.0 x
I
e
1 0 0.4 x I
e
21.02 Curr underload trip time 0 ... 30 s 0 0 5 s
21.03 Curr underload delay time 0 ... 10 s 0 0 1 s
21.04 Curr underload out 0 ... 127 0 126 0000100
21.05 Curr underload On / Off 0 0 Off
21.06 Pwr factor underload level 0.0 ... 1.0 2 0 0.50
21.07 Pwr factor underload trip
time
0 ... 30 s 0 0 5 s
21.08 Pwr factor underload delay
time
0 ... 10 s 0 0 1 s
21.09 Pwr factor underload out 0 ... 127 0 127 0000100
21.10 Pwr factor underload On / Off 0 0 Off
7
