Parameter
number
Description Setting range Number of
decimal
Fieldbus
ID
Default value Actual
setting
21 Warnings list 2
21.11 Current imb level 10 ... 80 % 0 102 70 %
21.12 Current imb out 0 ... 127 0 103 0000100
21.13 Current imbalance On / Off 0 101 Off
22 Warnings list 3
22.01 Over voltage level 208 ... 850 V 0 104 208 V
22.02 Over voltage trip time 0.1 ... 100.0 s 1 105 1.0 s
22.03 Over voltage out 0 ... 127 0 107 0000100
22.04 Over voltage On / Off 0 106 Off
22.05 Under voltage level 208 ... 850 V 0 108 208 V
22.06 Under voltage trip time 0.1 ... 100.0 s 1 109 1.0 s
22.07 Under voltage out 0 ... 127 0 111 0000100
22.08 Under voltage On / Off 0 110 Off
22.09 Voltage imb level 1 ... 100 0 119 5
22.10 Voltage imb out 0 ... 127 0 120 0000100
22.11 Voltage imbalance On / Off 0 118 Off
23 Warnings list 4
23.01 EOL time-to-trip time 1 ... 1000 s 0 114 5 s
23.02 EOL time-to-trip out 0 ... 127 0 112 0000100
23.03 EOL time-to-trip On / Off 0 113 Off
23.04 THD(U) level 1 ... 100 % 0 116 10 %
23.05 THD(U) out 0 ... 127
0 117 0000100
23.06 THD(U) On / Off 0 115 Off
23.07 Short circuit out 0 ... 127 0 129 0000100
23.08 Short circuit On / Off 0 121 Off
24 Warnings list 5
24.04 Faulty fan out 0 ... 127 0 80 0000100
24.05 Faulty fan On / Off 0 79 Off
24.06 Modbus_RTU w/o auxport
out
0 ... 127 0 176 0000100
25 Internal faults
25.01 Shunt fault out 0 ... 127 0 42 0000001
25.02 Shunt fault op Stop-Manual, Stop-Automatic 0 0 Stop-Manual
25.03 Short circuit out 0 ... 127 0 50 0000001
25.04 Short circuit fault op Stop-Manual, Stop-Automatic 0 0 Stop-Manual
25.05 Open circuit thyr out 0 ... 127 0 44 0000001
25.06 Open circuit thyr op Stop-Manual, Stop-Automatic 0 0 Stop-Manual
25.07 Thyristor OL out 0 ... 127 0 47 0000001
25.08 Thyristor OL op Stop-Manual, Stop-Automatic 0 0 Stop-Manual
25.09 Heat sink over temp out 0 ... 127 0 48 0000001
25.10 Heat sink over temp op Stop-Manual, Stop-Automatic 0 0 Stop-Manual
25.11 Unspecified fault out 0 ... 127 0 43 0000001
25.12 Unspecified fault op Stop-Manual, Stop-Automatic 0 0 Stop-Manual
26 External faults
26.01 Phase loss out 0 ... 127 0 96 0000001
26.02 Phase loss op Stop-Manual, Stop-Automatic 0 0 Stop-Manual
26.03
Bad network out 0 ... 127 0 36 0000001
26.04 Bad network op Stop-Manual, Stop-Automatic 0 0 Stop-Manual
26.05 Low supply voltage out 0 ... 127 0 46 0000001
26.06 Low supply voltage op Stop-Manual, Stop-Automatic 0
-
Stop-Manual
26.07 High current out 0 ... 127 0 49 0000001
26.08 High current op Stop-Manual, Stop-Automatic 0 0 Stop-Manual
26.11 Faulty connection out 0 ... 127 0
-
0000001
26.12 Faulty connection op Stop-Manual, Stop-Automatic 0 0 Stop-Manual
27.01 Language English, Spanish, Finnish, French, Italian
Dutch, Polish, Portuguese, Russian, Swedish
Turkish, Chinese (simplified chinese), Arabic
Czech, German
0 173 English
27.02 Basic set-up at power on Yes, No 0 - Yes
7
